Main Unit

Machine Type

A3 Monochrome Laser Multifunctional

Core Functions

Print, Copy, Scan, Send, Store and Optional Fax

Processor

Canon Dual Custom Processor (Shared)

Control Panel

10.1 inch TFT LCD WSVGA Colour Touch panel

Memory

Standard: 3.0 GB RAM

Hard Disk Drive

Standard: 320GB (Available disk space: 250GB)
Maximum: 1TB

Mirroring Hard Disk Drive

Optional: 250GTB, 1TB

Interface Connection

Network
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n);
Optional: NFC, Bluetooth Low Energy

Others
Standard: USB 2.0 (Host) x2, USB 3.0 (Host) x1, USB 2.0 (Device) x1;
Optional: Serial Interface, Copy Control Interface

Paper Supply Capacity (A4, 80 gsm)

Standard: 1,200 sheets (2 x 550-sheet cassette,  100-sheet multi-purpose tray)
Maximum: 6,350 sheets (with High Capacity Cassette Feeding Unit-B1 and Paper Deck Unit-F1)

Paper Output Capacity (A4, 80 gsm)

Standard: 250 sheets
Maximum: 3,350 sheets (with Buffer Pass-N1 + Staple Finisher-Y1 or Booklet Finisher-Y1)

Finishing Capabilities

Standard: Collate, Group
With Inner Finisher : Collate, Group, Offset, Staple, Hole Punch*1, ECO-Staple , Staple-on-Demand
With External Finisher*2 : Collate, Group, Offset, Staple, Booklet*3, Hole Punch*4, ECO-Staple, Staple-on-Demand

Supported Media Types

Paper Cassette (1/2):
Thin, Plain, Thick, Colour, Recycled, Pre-punched

Multi-purpose tray:
Thin, Plain, Thick, Colour, Recycled, Pre-punched, Transparency, Tracing*5, Label, Bond, Envelope

Supported Media Sizes

Upper Cassette 1:
Standard size: A4, A4R, A5R, B4, B5, B5R, Foolscap, India Legal , F4A
Custom size: Min. 139.7 x 182.0 mm up to 297.0 x 390.0 mm

Lower Cassette 2:
Standard size: A3, A4, A4R, A5R, B4, B5, B5R,Foolscap, India Legal , F4A
Custom size: Min. 139.7 x 182.0 mm up to 297.0 x 431.8 mm

Multi-purpose tray:
Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, Foolscap, India Legal, F4A, Envelopes [No. 10(COM 10), Monarch, ISO-C5, DL]
Custom Size: Min. 98.0 x 148.0 mm to 297.0 x 431.8 mm
Free Size: Min. 98.0 x 148.0 mm to 297.0 x 431.8 mm

Supported Media Weights

Paper Cassettes (1/2): 60 to 128 gsm
Multi-purpose tray: 52 to 220 gsm (Thin: vertical grain paper feed only: 52-59gsm)
Duplex: 60 to 105 gsm

Warm-up Time

From Power On: 30 Seconds or Less*6
From Sleep Mode: 10 Seconds or Less
Quick Startup Mode: 4 seconds or less*7

Dimensions (W x D x H)

With platen cover: 587 x 728 x 822 mm
With Single Pass DADF-A1: 587 x 740 x 945 mm
With DADF-AV1: 587 x 750 x 926 mm

Installation Space (W x D)

Basic:
889 x 1,160 mm (with Platen Cover Type W + Multi-purpose tray open/extension tray extended + Paper Cassette open)
889 x 1,172 mm (with Single Pass DADF-A1 + Multi-purpose tray open/extension tray extended + Paper Cassette open)
889 x 1,182 mm (with DADF-AV1 + Multi-purpose tray open/extension tray extended + Paper Cassette open)

Fully Configured:
1,811 x 1,270 mm (with Single Pass DADF-A1 + Paper Deck Unit-F1 + Booklet Finisher-Y1 with Saddle unit drawn +Paper Cassette open)
1,811 x 1,280 mm (with DADF-AV1 + Paper Deck Unit F1 + Booklet Finisher-Y1 with Saddle unit drawn +Paper Cassette open)

Weight

iR-ADV 4551i III/4545i III/4535i III:
With Platen Cover Type W: Approx. 75 kg including toner
With Single Pass DADF-A1: Approx. 87 kg including toner
With DADF-AV1: Approx. 82 kg including toner

iR-ADV 4525i III:
With Platen Cover Type W: Approx. 74 kg including toner
With Single Pass DADF-A1: Approx. 86 kg including toner
With DADF-AV1: Approx. 81 kg including toner

Print

Print Speed (ppm)

iR-ADV 4551i III
Up to 51 (A4), up to 25 (A3), up to 37 (A4R), up to 20 (A5R)

iR-ADV 4545i III
Up to 45 (A4), up to 22 (A3), up to 32 (A4R), up to 20 (A5R)

iR-ADV 4535i III
Up to 35 (A4), up to 22 (A3), up to 32 (A4R), up to 20 (A5R)

iR-ADV 4525i III
Up to 25 (A4), up to 15 (A3), up to 17 (A4R/A5R)

Print Resolution (dpi)

Data processing resolution: 1,200 x 1,200, 600 x 600
Output resolution: 1,200 x 1,200

Page Description Languages

Standard: UFR II (standard), PCL 6
Optional: Adobe PS 3

Direct Print

Direct printing available from USB memory, Advanced space, Remote UI and Web Access*8
Supported file types: TIFF, JPEG, PDF, EPS, and XPS

Printing from Mobile and Cloud

AirPrint, Mopria, Google Cloud Print, and Canon Business Print, and uniFLOW Online

Fonts

PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T*9 (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts*10

PS fonts: 136 Roman

Operating System

UFRII: Windows 7 / 8.1 /10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016, MAC OS X (10.9 or later)
PCL: Windows 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016
PS: Windows 7 / 8.1 / 10 / Server 2008 / Server 2008 R2 / Server 2012 / Server 2012 R2 / Server 2016, MAC OS X (10.9 or later)
PPD: MAC OS X (10.3.9 or later), Windows 7 / 8.1/ 10

Copy

Scan

Selectable type

Single-pass Duplexing Automatic Document Feeder or Duplexing Automatic Document Feeder

Document Feeder Paper Capacity (80 gsm)

SINGLE PASS DADF-A1: 150 Sheets
DADF-AV1: 100 Sheets

Acceptable Originals and Weights

Platen: Sheet, Book, 3-Dimensional Objects (Height: Up to 50 mm, Weight: up to 2kg)

Document Feeder: Sheet media weight
SINGLE PASS DADF-A1:
1-sided scanning: 38 to 157 gsm (BW) /64 to 157 gsm (CL)
2-sided scanning: 50 to 157 gsm (BW) /64 to 157 gsm (CL)
DADF-AV1:
1-sided scanning: 38 to 128 gsm (BW) /64 to 128 gsm (CL)
2-sided scanning: 50 to 128 gsm (BW) /64 to 128 gsm (CL)

Supported Media Sizes

Platen: Max. scanning size: 297.0 x 431.8 mm
Document Feeder media size: Single Pass DADF-A1: A3, A4, A4R, A5, A5R, B4, B5, B5R, B6R
Custom size: 128.0 x 139.7 mm to 304.8 x 431.8 mm
DADF-AV1: A3, A4, A4R, A5, A5R, B4, B5, B5R, B6
Custom size: 139.7 x 128 mm to 297.0 x 431.8 mm

Scan Speed (A4, BW/CL)

SINGLE PASS DADF-A1:
1-sided Scanning (ipm): 80 /80 (300dpi, Send), 80 (600 dpi, BW Copy)
2-sided Scanning (ipm): 160 /160 (300dpi, Send), 150 (600 dpi, BW Copy)

DADF-AV1:
1-sided Scanning(ipm): 70 /70 (300dpi, Send), 51 (600 dpi, BW Copy)
2-sided Scanning (ipm) : 35 /35 (300dpi, Send), 25.5 (600 dpi, BW Copy)

Scan Resolution (dpi)

600 x 600, 400 x 400, 300 x 300, 200 x 400, 200 x 200, 200 x 100i, 150 x 150, 100 x 100

Pull Scan Specifications

Colour Network ScanGear2. For both TWAIN and WIA
Supported OS: Windows 7/8.1/10
Windows Server 2008/Server 2008 R2/Server 2012/Server 2012 R2/Server 2016

Send

Fax

Optional / Standard

Optional on all models

Maximum Number of Connection Lines

4

Modem Speed

Super G3: 33.6 kbps
G3: 14.4 kbps

Compression Method

MH, MR, MMR, JBIG

Resolution (dpi)

400 x 400, 200 x 400, 200 x 200, 200 x 100

Sending / Recording Size

A3, A4, A4R, A5*11, A5R*11, B4, B5*12, B5R*11

FAX / Memory

Up to 30,000 pages

Speed Dials

Max. 200

Group Dials /  Destinations

Max. 199 dials

Sequential Broadcast

Max. 256 addresses

Memory Backup

Yes

Store

Mail Box (Number supported)

100 User Inboxes, 1 Memory RX Inbox,
50 Confidential Fax Inboxes,
30,000 Maximum Pages Stored

Advanced Box

Communication Protocol: SMB or WebDAV
Supported Client PC: Windows (Windows 7 / 8.1 / 10)
Concurrent Connections (Max.): SMB: 64, WebADV: 3 (Active Sessions)

Advanced Box Available Disc Space

Approx. 16GB (Standard HDD)
Approx. 480GB (with option 1TB HDD)

Memory Media

Standard: USB Memory

Security

Authentication

Standard: User Authentication (Picture Login/Keyboard Authentication), DepartmentID Authentication, Access Management System, uniFLOW Online Express Cloud based management software
Optional: My Print Anywhere secure print (Requires uniFLOW)

Data

Standard: Trusted Platform Module (TPM), Hard Disk Password Lock, Hard Disk Drive Erase, Mail Box Password Protection, Hard Disk Drive Encryption(FIPS140-2 Validated)
Optional: Hard Disk Drive Mirroring, Hard Disk Drive removal, IEEE 2600.2 Common Criteria Certification, Data Loss Prevention (Requires uniFLOW,iWSAM Express)

Network

Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, S/MIME

Document

Standard: Secure Print, Adobe LiveCycle® Rights Management ES2.5 Integration, Encrypted PDF, Encrypted Secure Print, Device signature, Secure Watermarks
Optional: User signature, Document Scan lock

Environmental

Operating Environment

Temperature: 10 to 30 ºC
Humidity: 20 to 80 % RH (Relative Humidity)

Power Source

iR-ADV 4551i: 220-240 III (±10 %), 50/60 Hz (±2 Hz), 5.6 Amp
iR-ADV 4545i/4535i III: 220-240 V (±10 %), 50/60 Hz (±2 Hz), 5.2 Amp
iR-ADV 4525i: 220-240 III (±10 %), 50/60 Hz (±2 Hz), 4.3 Amp

Power Consumption

Maximum: Approx. 1,500 W
Standby: Approx. 37 W*13
Sleep mode: Approx. 0.9 W*14

Consumables

Paper Supply Options

Hardware Accessories

Security Options

System and Controller options

Other Options

  1. Requires Inner 2/3 Hole Puncher-C1 or Inner 2/F4 Hole Puncher-C1.
  2. Requires Buffer Pass-N1.
  3. Requires Booklet Finisher-Y1.
  4. Requires 2/3 HOLE PUNCHER UNIT-A1 or 2/4 HOLE PUNCHER UNIT-A1.
  5. Some types of tracing paper cannot be used.
  6. Time from device power-on, until copy ready.
  7. Time from device power-on to when key operations can be performed on the touch panel display.
  8. Only PDF print from websites is supported.
  9. Requires optional PCL International Font Set-A1.
  10. Requires optional Barcode Printing Kit-D1.
  11. Sent as A4.
  12. Sent as B4.
  13. Reference value: measured one unit.
  14. 0.9W sleep mode may not be possible in all circumstances due to certain settings.
